Staunch Perkins 110kva Generator STPG110R-M

Store / Generators / Large Diesel / Three Phase 415v
AU$0.00
In stock
Product Details
GENERATOR SPECS
Prime Rated Output 100 kVA
Standby Rated Output 110 kVA
Rated Speed 1500 r.p.m.
Standard Voltage 415V
Available Voltages 240-480V
Rated at power factor 0.8 Cos Phi
ENGINE SPECS
Prime Power 95.5kW
Standby Power 112kW
Manufacturer PERKINS
Model 1104C-44TAG2
Engine Type Diesel 4 strokes-cycle
Injection Type Direct
Aspiration Type Natural
Cylinders Arrangement Vertical in line
Bore and Stroke 105 x 127 mm
Displacement 4.41 L
Cooling System Water – cooled
Lube Oil Specifications SAE 3 class 15W40 / API grade CD,CF
Fuel Consumption 100% PRP 24.3 l/h
Fuel Consumption 75 % PRP 17.9 l/h
Fuel Consumption 50 % PRP 12.3 l/h
Total Oil Capacity 16.1L
Total Coolant Capacity 27.2 L
Governor Mechanical
Air Filter Dry – Single Element
Inner diameter exhaust pipe mm
ALTERNATOR SPECS
MARELLI MJB 225 MA4
Poles 4
Phase 3
FUEL SYSTEM
Fuel Specifications Diesel
Fuel Tank volume 600L
Autonomy 100% load 24 Hours
Weight and Dimensions
Length mm
Height mm
Width mm
Weight (dry) Kg
Noise level @ 7m 69dB
