Staunch Perkins 220kva Generator STPG220R-M

Store / Generators / Large Diesel / Three Phase 415v
AU$0.00
In stock
Product Details
GENERATOR SPECS
Prime Rated Output 200 kVA
Standby Rated Output 220 kVA
Rated Speed 1500 r.p.m.
Standard Voltage 415V
Available Voltages 240-480V
Rated at power factor 0.8 Cos Phi
ENGINE SPECS
Prime Power 187kW
Standby Power 205kW
Manufacturer PERKINS
Model 1306C-E87TAG3
Engine Type Diesel 4 strokes-cycle
Injection Type Direct
Aspiration Type Natural
Cylinders Arrangement Vertical in line
Bore and Stroke 116.6 x 135.9 mm
Displacement 8.7 L
Cooling System Water – cooled
Lube Oil Specifications SAE 3 class 15W40 / API grade CD,CF
Fuel Consumption 100% PRP 26.4 l/h
Fuel Consumption 75 % PRP 45.2 l/h
Fuel Consumption 50 % PRP 35 l/h
Total Oil Capacity 37.2L
Total Coolant Capacity 2.61 L
Governor Mechanical
Air Filter Dry – Single Element
Inner diameter exhaust pipe mm
ALTERNATOR SPECS
STAMFORD STG200
Poles 4
Phase 3
FUEL SYSTEM
Fuel Specifications Diesel
Fuel Tank volume 800L
Autonomy 100% load 24Hours
Weight and Dimensions
Length mm
Height mm
Width mm
Weight (dry) Kg
Noise level @ 7m 69dB
