Staunch Perkins 385kva Generator STPG385R-M

Store / Generators / Large Diesel / Three Phase 415v
AU$0.00
In stock
Product Details
GENERATOR SPECS
Prime Rated Output 350 kVA
Standby Rated Output 385 kVA
Rated Speed 1500 r.p.m.
Standard Voltage 415V
Available Voltages 240-480V
Rated at power factor 0.8 Cos Phi
ENGINE SPECS
Prime Power 324kW
Standby Power 368kW
Manufacturer PERKINS
Model 2206A-E13TAG2
Engine Type Diesel 4 strokes-cycle
Injection Type Direct
Aspiration Type Natural
Cylinders Arrangement Vertical in line
Bore and Stroke 130 x 157 mm
Displacement 12.5 L
Cooling System Water – cooled
Lube Oil Specifications SAE 3 class 15W40 / API grade CD,CF
Fuel Consumption 100% PRP 71 l/h
Fuel Consumption 75 % PRP 54 l/h
Fuel Consumption 50 % PRP 37 l/h
Total Oil Capacity 40 L
Total Coolant Capacity 51.4 L
Governor Mechanical
Air Filter Dry – Single Element
Inner diameter exhaust pipe mm
ALTERNATOR SPECS
STAMFORD MJB 315 SB4
Poles 4
Phase 3
FUEL SYSTEM
Fuel Specifications Diesel
Fuel Tank volume 1700 L
Autonomy 100% load 24 Hours
Weight and Dimensions
Length mm
Height mm
Width mm
Weight (dry) Kg
Noise level @ 7m 69dB
