Staunch Perkins 700kva Generator STPG700R-M

Store / Generators / Large Diesel / Three Phase 415v
AU$0.00
In stock
Product Details
GENERATOR SPECS
Prime Rated Output 650 kVA
Standby Rated Output 700 kVA
Rated Speed 1500 r.p.m.
Standard Voltage 415V
Available Voltages 240-480V
Rated at power factor 0.8 Cos Phi
ENGINE SPECS
Prime Power 584 kW
Standby Power 628 kW
Manufacturer PERKINS
Model 2806A-E18TAG2
Engine Type Diesel 4 strokes-cycle
Injection Type Direct
Aspiration Type Natural
Cylinders Arrangement Vertical in line
Bore and Stroke 145 x 183 mm
Displacement 18.1 L
Cooling System Water – cooled
Lube Oil Specifications SAE 3 class 15W40 / API grade CD,CF
Fuel Consumption 100% PRP 132 l/h
Fuel Consumption 75 % PRP 97 l/h
Fuel Consumption 50 % PRP 66 l/h
Total Oil Capacity 62 L
Total Coolant Capacity 61 L
Governor Mechanical
Air Filter Dry – Single Element
Inner diameter exhaust pipe mm
ALTERNATOR SPECS
STAMFORD MJB 355 MA4 / HC54F1
Poles 4
Phase 3
FUEL SYSTEM
Fuel Specifications Diesel
Fuel Tank volume 3200 L
Autonomy 100% load 24 Hours
Weight and Dimensions
Length TBA
Height TBA
Width TBA
Weight (dry) TBA
Noise level @ 7m 69dB
