Staunch Scania 330kva Generator STSG330R-M

Staunch Scania 330kva Generator STSG330R-M

Store / Generators / Large Diesel / Three Phase 415v
AU$0.00
In stock
Product Details
UPC: 0
Brand: no
GENERATOR SPECS
Prime Rated Output 300 kVA
Standby Rated Output 330 kVA
Rated Speed 1500 r.p.m.
Standard Voltage 415 V
Available Voltages 240/415 V
Rated at power factor 0.8 Cos Phi
ENGINE SPECS
Prime Power 267 kW
Standby Power 294 kW
Manufacturer SCANIA
Model DC09-072A(REF 0213)
Injection Type Direct
Aspiration Type Turbocharged, air cooled
Cylinders Arrangement 5 in line
Bore and Stroke 130 x 140 mm
Displacement 9.3 L
Cooling System Air charge cooled
Fuel Consumption 100% PRP 62.1 l/h
Fuel Consumption 75 % PRP 43 l/h
Fuel Consumption 50 % PRP 30.5 l/h
Total Oil Capacity 36 L
Total Coolant Capacity 37 L
Governing Class
Air Filter Dry – Single Element
Exhaust Flow 24 kg per minute
ALTERNATOR SPECS
MARELLI MJB 315 SA4
Poles 4
Phase Three
FUEL SYSTEM
Fuel Specifications Diesel
Fuel Tank volume 1,350 L
Autonomy 100% load 24 Hours
Weight and Dimensions
Length 1624 mm
Height 1064 mm
Width

1463 mm
Weight (dry) 4,300 Kg
Noise level @ 7m 65 dB
