Staunch Yanmar 50kva Generator STYG50R-1M

Store / Generators / Large Diesel / Single Phase 240v
AU$0.00
In stock
Product Details
GENERATOR SPECS
Prime Rated Output 29.0 kVA
Standby Rated Output 32.0 kVA
Rated Speed 1500 r.p.m.
Standard Voltage 240 V
Available Voltages 240/415 V
Rated at power factor 1.0 Cos Phi
ENGINE SPECS
Prime Power 37.7 kW
Standby Power 41.8 kW
Manufacturer YANMAR
Model 4TNV98T
Engine Type Diesel 4 strokes-cycle
Injection Type Direct
Aspiration Type Turbo
Cylinders Arrangement 4 – L
Bore and Stroke 98 x 110 mm
Displacement 3.319 L
Cooling System coolant
Lube Oil Specifications SAE 3 class 10W30 / API grade CD,CF
Fuel Consumption 100% PRP 9.16 l/h
Fuel Consumption 75 % PRP 6.94 l/h
Fuel Consumption 50 % PRP 4.89 l/h
Total Oil Capacity 11.2 L
Total Coolant Capacity 9.0 L
Governor Electrical
Air Filter Dry – 4” Single Element
Inner diameter exhaust pipe 54 mm
ALTERNATOR SPECS
MARELLI MXB 180 LA4
Poles 4
Phase Single
FUEL SYSTEM
Fuel Specifications Diesel
Fuel Tank volume 220 L
Autonomy 100% load 24 Hours
Weight and Dimensions
Length 2280 mm
Height 1615 mm
Width 980 mm
Weight (dry) 1260 Kg
Noise level @ 7m 66 dB
